Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4

Certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
I'm Online Chat Now

Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4

Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4
Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4

Large Image :  Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4

Product Details:
Place of Origin: CHINA
Brand Name: MTM/DINGXING
Certification: ISO/CE
Model Number: MTM-145E4
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 50000-80000/SET
Packaging Details: Meteorological anti-rust film and steel bottom bracket
Delivery Time: 30 DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10 SET/MONTH

Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4

Description
Max. Laminating Width (mm): 1080 Max Sheet W×L (mm): 1080X1450
Min Sheet W×L (mm): 350×350 Paper Thickness (gsm): 100-500
High Light:

Hot Knife Thermal Film Laminator Machine

,

Automatic paper film laminating machine

,

Hot Knife paper film laminating machine

MTM-145E4 Automatic Hot Knife Film Laminator

Description Quantity

Automatic Hot Knife Film Laminator 1 SET Model: MTM-145E4

Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 0







Automatic Hot Knife Film Laminator

Hot knife cutting blade is suitable for all films, especially PET film,metalized films(metpet) etc..

General features:

●High efficient: Power consumption of hot knife is as low as 0.4kW.

●No tail film: knife blade temperatures rose to 400 °C within 3 seconds to ensure net and quick cutting.

●High Speed Cut: 80 meters per minute.

●High cut accuracy: Double laser self-aligning device ensures perfect cutting effect.

●High precision ceramic anilox coating roller as standard to ensure super even gluing, no glue stripes, longer roller life, anti-corrosion, glue saving(5g/sqm).

●Non-stop paper feeder system enables continuous feeding without machine stop to minimize waste film.

●Electric thermal powder-removal system ensures clean paper surface to enhance lamination quality.

●Electric glue drying system combined with heat recirculation system to guarantee quick heating to dry the glue and power saving.(30kW consumption in production)



Specification Sheet



MODEL MTM-108E MTM-145E

Max. laminating width (mm)



1080 1080
Max sheet W×L (mm) 1080×950 1080X1450
Min sheet W×L (mm) 350×350 350×350
Paper thickness (gsm) 100-500 100-500
Film thickness (µm) 6--25 6--25
Machine speed (m/min) 10-70 10-70
Machine Dimension L*W*H (mm) 10765*2754*2926 12994*2754*2926
Machine weight (kgs) 8600 10200

Total power (kw)



68kW

30kW(Production)

68kW

30kW(Production)





Standard Function Sections:

  1. Automatic feeder

-Servo control automatic high speed feeder.

-Non-stop feeding device.



Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 1







B. Side lay register

-Mechanical side lay register

-High speed paper registration.

Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 2



C. Powder Removal System



-Electrostatic paper powder collector as standard

- to increase paper brightness and reduce the amount of glue.



Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 3

D. Laminating Section







- Electromagnetic heating system , quick heating , energy saving and environmental protection.


Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 4



E. Coating System:(with Electromagnetic energy-saving system)



- Precision ceramic roller coating , glue saving.


Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 5





F. Drying system:(with Electromagnetic energy-saving system)



- Hot air circulation system , high speed drying , power saving.



G. Automatic cutting







-STEINEMANN hot knife cutting system suitable for PET/OPP/PVC/Aluminum foil film cutting

-Servo automatic tracking control

-Servo control tension

-Laser positioning, accurate and precise

Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 6





  1. Automatic Non-stop Stacker

-Three sides paper aligning , automatic speed reduction , double sheet removal device.

Automatic Hot Knife Paper Thermal Film Laminator Machine MTM-145E4 7
