Name: Grey Paperboard High Speed Flute Laminator 2100mmx2100mm Litho Laminator
Brand: Dongtai Dingxing Machinery Technology Co., Ltd
SKU: DX-2100
Price: 70,000.00 USD
Availability: InStock

Home > products > High Speed Flute Laminator >

Grey Paperboard High Speed Flute Laminator 2100mmx2100mm Litho Laminator

Grey Paperboard High Speed Flute Laminator

2100mmx2100mm Litho Laminator

2100mmx2100mm High Speed Flute Laminator

Place of Origin:

CHINA

Brand Name:

DINGXING/DINGYI

Certification:

ISO/CE

Model Number:

DX-2100

Request A Quote

Product Details

Color:

Customizable

Function:

Two Sheet Lamination

Part Brand:

International Professional Leading Brand

Main Market:

Europe And North America

Highlight:

Grey Paperboard High Speed Flute Laminator

2100mmx2100mm Litho Laminator

2100mmx2100mm High Speed Flute Laminator

Payment & Shipping Terms

Minimum Order Quantity

Price

USD 40000-100000/SET

Packaging Details

Meteorological anti-rust film and steel bottom bracket

Delivery Time

60 DAYS

Payment Terms

L/C, D/A, D/P, T/T

Supply Ability

6 SET/MONTH

Automatic Corrugated Cardboard Flute Laminator CE Certified

Get Best Price

Video

Cardboard Automatic High Speed Flute Laminator Inline With Electric Driven

Get Best Price

Video

7 Layers Corrugate High Speed Flute Laminator 150m/Min DX-1450

Get Best Price

Video

120-600gsm Top Sheet Automatic 5 Ply Flute Laminator ISO CE

Get Best Price

+86 18678943457

tony@dingxingmachinery.com

86-515-85571076

Contact Now

Product Description

DX-2100 HIGH LAMINATION ACCURACY FLUTE LAMINATOR

Leading-edge L .itho Feeder ensures stable running at high speed and no extra adjustment for different job. . Servo shaftless back feeder, make the top sheet feeding paper overlap. fast and efficiency. " Dual servo bottom sheet feeder ensures smooth feeding of warping and multi ply paperboards. Computerized high-speed lamination at max. speed of 12,000 sheets per hour(Paper length:600mm)

Feeder Base: Low E-type piling table ensures direct paper feeding by pallet cart. Railway truck pre-loader is optional. . Gluing System:High- precision gluing rollers, glue side stopper. auto glue level controller. no overflow at high speed and glue recirculation system. . Compensation Aligning System: multiple sensors detect relative position of bottom paper .while servo motors ensure dependent upper paperdelivery compensation to guarantee precise aligning of two sheets. . Electrical Control System: Human Machine Interface with PLC control, warning light indicator, automatic detection of production condition,irregularities and job record. CE certified.

Model/Modelo

DX-1450

DX-1650

DX-1650XL

DX-2050

DX-2100

Max. SheetSize(WXL)

Tamaño máximo (WXL)

1450mmx1450mm

(57’x57’)

1650mmx1450mm

(65’x57’)

1650mmx1650mm

(65’x65’)

2050mmx1650mm

(817’x65’)

2100mmx2100mm

(83x83’)

Min. Sheet Size(WXL)

Tamaño mínimo de tabla

400mmx400mm

(16’x16’)

400mmx400mm

(16’x16’)

400mmx400mm

(16’x16’)

550mmx450mm

(21’x18’)

550mm*450mm

(22x18’)

Thickness of Upper Paper

Grosor del papel

120~600gsm

Thickness of Bottom Paper

Grosor de fondo

0.5-10mm

A-N Flute single layer/3 layers/5 layers /7 layers Corrugate board, Grey Board and Board

Flauta A-N de una capa / 3 capas / 5 capas / 7 capas Tablero corrugado, tablero gris y tablero

Max. Speed

Velocidad máxima

150m/min (Subject to board quality and specification)

Laminating Precision

Precisión de laminado

±1.5mm

±2mm

Power

Poder

200V/-380V3-25HP
