Grey Board Cardboard Laminating Machine PLC Control Automatic Lamination Machine

Certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
I'm Online Chat Now

Grey Board Cardboard Laminating Machine PLC Control Automatic Lamination Machine

Grey Board Cardboard Laminating Machine PLC Control Automatic Lamination Machine
Grey Board Cardboard Laminating Machine PLC Control Automatic Lamination Machine Grey Board Cardboard Laminating Machine PLC Control Automatic Lamination Machine Grey Board Cardboard Laminating Machine PLC Control Automatic Lamination Machine Grey Board Cardboard Laminating Machine PLC Control Automatic Lamination Machine

Large Image :  Grey Board Cardboard Laminating Machine PLC Control Automatic Lamination Machine

Product Details:
Place of Origin: CHINA
Brand Name: DINGYI
Certification: ISO/CE
Model Number: DX-1210
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 20000-40000/SET
Packaging Details: Meteorological anti-rust film and steel bottom bracket
Delivery Time: 30 DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 5 SET/MONTH

Grey Board Cardboard Laminating Machine PLC Control Automatic Lamination Machine

Description
Color: Customizable Function: Two Cardboard Lamination
Part Brand: International Professional Leading Brand Accuracy: ±0.5mm
High Light:

Grey Board Cardboard Laminating Machine

,

PLC Control Automatic Lamination Machine

,

Cardboard Laminating Machine PLC Control

Specifications

Model DX-1210
Max. Sheet Size(mm) 1200Wx1000L
Min. Sheet Size(mm) 450Wx450L
Thickness of Upper Paper 100-800g/m²
Thickness of Bottom Paper 180-1800g/m²
Max. Speed 105pcs/min (Subject to Paper Quality)
Laminating Precision ±0.5mm(Standard smooth paperboard)
Total Weight 7000kg
Dimensions 8900mm*2470mm*2180mm
Operation Space 3M×12M
Power AC380V/50HZ/16KW


**Specifications are subject to change without notice



Function

Lamination of two paperboards at precision of ±0.5mm, this equipment is capable to laminate and glue combination of thin paper, art paper, cardboard, gray cardboard or thick paper board together to increase the material strength and thickness, or being laminated to have special effect. After shearing or mold cutting, the laminated products can be made to be hang-tag, display card, packing box, material pad, hard cover book, photo album, sun shield or inner lining of piece goods, product demonstration book, puzzle, toys, handbag or decoration materials.
