Corrugated And Cardboard Flute Laminating Machine Automatic

Certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
I'm Online Chat Now

Corrugated And Cardboard Flute Laminating Machine Automatic

Corrugated And Cardboard Flute Laminating Machine Automatic
Corrugated And Cardboard Flute Laminating Machine Automatic Corrugated And Cardboard Flute Laminating Machine Automatic Corrugated And Cardboard Flute Laminating Machine Automatic Corrugated And Cardboard Flute Laminating Machine Automatic Corrugated And Cardboard Flute Laminating Machine Automatic Corrugated And Cardboard Flute Laminating Machine Automatic

Large Image :  Corrugated And Cardboard Flute Laminating Machine Automatic

Product Details:
Place of Origin: SHENZHEN
Brand Name: DINGXING/DINGYI
Payment & Shipping Terms:
Price: $65,000.00/sets >=1 sets
Packaging Details: standard packing
Supply Ability: 10 Set/Sets per Month

Corrugated And Cardboard Flute Laminating Machine Automatic

Description
Type: Laminating Machine Applicable Industries: Manufacturing Plant, Packing Industry
Showroom Location: Canada, United States, Poland Video Outgoing-inspection: Provided
Machinery Test Report: Provided Warranty Of Core Components: 2 Years
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pump Condition: New
Application: Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, APPAREL Packaging Type: Cartons
Packaging Material: Paper, Wood Automatic Grade: Automatic
Driven Type: Electric Voltage: Customized
Dimension(L*W*H): 11985*2420*2500 Weight: 7000 KG
Warranty: 1 Year Key Selling Points: High-accuracy
Machine Type: Cardboard Laminator Max. Sheet Size(mm): 1200Wx720L
Min. Sheet Size(mm): 450Wx450L Machine Speed: 105pcs/min
Bottom Paper Thickness: A,B,C,E,F Corrugated Paper, Industrial Paperboard After Warranty Service: Video Technical Support, Online Support, Spare Parts,
Certificate: CE ISO Business Type: Manufacturer Direct Sales
After-sales Service Provided:: Engineers Service Machinery Overseas, Installation, Online Support, Marketing Type: Hot Product 2021
Port: Qingdao
High Light:

Cardboard Flute Laminating Machine

,

105 Pcs/min Flute Laminating Machine

,

PLC Corrugated Flute Laminator

High Quality Corrugated Flute Laminating And Cardboard Flute Laminating Machine

Corrugated And Cardboard Flute Laminating Machine Automatic 0

Corrugated And Cardboard Flute Laminating Machine Automatic 1Corrugated And Cardboard Flute Laminating Machine Automatic 2Corrugated And Cardboard Flute Laminating Machine Automatic 3Corrugated And Cardboard Flute Laminating Machine Automatic 4
Model
DX-1207
DX-1210
DX-1410
Max. Sheet Size(mm)
1200Wx720L
1200Wx1000L
1410Wx1000L
Min. Sheet Size(mm)
450Wx450L
400*450mm
400*450mm
Thickness of Upper Paper
100-800g/m²
120-600/m²
120-600/m²
Thickness of Bottom Paper
180-1800g/m²


Max. Speed
105pcs/min
105pcs/min (Subject to Paper Quality)

Laminating Precision
±0.5mm(Standard smooth paperboard)


Total Weight
7000kg
7000kg
7500kg
Total Length
8900mm
8900mm
8900mm
Operation Space
3M×12M
3M×12M
3M×12M
Power
AC380V/50HZ/16KW
AC380V/50HZ/16KW
AC380V/50HZ/16KW
Corrugated And Cardboard Flute Laminating Machine Automatic 5
Corrugated And Cardboard Flute Laminating Machine Automatic 6
Corrugated And Cardboard Flute Laminating Machine Automatic 7


Corrugated And Cardboard Flute Laminating Machine Automatic 8
