Product Details:
|
| Max. Laminating Width (mm): | 1080 | Max Sheet W×L (mm): | 1080×950 |
|---|---|---|---|
| Min Sheet W×L (mm): | 350×350 | Paper Thickness (gsm): | 100-500 |
| High Light: | Automatic Feeder Film Laminator Machine,Chain Knife Film Laminator Machine 68kW,68kW thermal film laminator |
||
MTM-108E3 Automatic Chain Knife Film Laminator
MTM-E Automatic Hot Knife Film Laminator
| Description | Quantity | ||
|
Automatic Chain Knife Film Laminator 1 SET Model: MTM-108E3
|
|||
Automatic Hot Knife Film Laminator
Hot knife cutting blade is suitable for all films, especially PET film,metalized films(metpet) etc..
General features:
●High efficient: Power consumption of hot knife is as low as 0.4kW.
●No tail film: knife blade temperatures rose to 400 °C within 3 seconds to ensure net and quick cutting.
●High Speed Cut: 80 meters per minute.
●High cut accuracy: Double laser self-aligning device ensures perfect cutting effect.
●High precision ceramic anilox coating roller as standard to ensure super even gluing, no glue stripes, longer roller life, anti-corrosion, glue saving(5g/sqm).
●Non-stop paper feeder system enables continuous feeding without machine stop to minimize waste film.
●Electric thermal powder-removal system ensures clean paper surface to enhance lamination quality.
●Electric glue drying system combined with heat recirculation system to guarantee quick heating to dry the glue and power saving.(30kW consumption in production)
Specification Sheet
| MODEL | MTM-108E | MTM-145E |
|
Max. laminating width (mm)
|
1080 | 1080 |
| Max sheet W×L (mm) | 1080×950 | 1080X1450 |
| Min sheet W×L (mm) | 350×350 | 350×350 |
| Paper thickness (gsm) | 100-500 | 100-500 |
| Film thickness (µm) | 6--25 | 6--25 |
| Machine speed (m/min) | 10-70 | 10-70 |
| Machine Dimension L*W*H (mm) | 10765*2754*2926 | 12994*2754*2926 |
| Machine weight (kgs) | 8600 | 10200 |
|
Total power (kw)
|
68kW 30kW(Production) |
68kW 30kW(Production) |
Standard Function Sections:
-Servo control automatic high speed feeder.
-Non-stop feeding device.
B. Side lay register
-Mechanical side lay register
-High speed paper registration.
C. Powder Removal System
-Electrostatic paper powder collector as standard
- to increase paper brightness and reduce the amount of glue.
D. Laminating Section
- Electromagnetic heating system , quick heating , energy saving and environmental protection.
E. Coating System:(with Electromagnetic energy-saving system)
- Precision ceramic roller coating , glue saving.
F. Drying system:(with Electromagnetic energy-saving system)
- Hot air circulation system , high speed drying , power saving.
G. Automatic cutting
-Chain knife cutting system suitable for PET/OPP/PVC film cutting
-Servo automatic tracking control
-Servo control tension
-Laser positioning, accurate and precise
-Three sides paper aligning , automatic speed reduction , double sheet removal device.
