Name: Becker Pump Chain Knife Film Laminator Machine Fully Automatic Laminating
Brand: Dongtai Dingxing Machinery Technology Co., Ltd
SKU: MTM-145E3
Price: 157,500.00 USD
Availability: InStock

Home > products > Chain Knife Film Laminator Machine >

Becker Pump Chain Knife Film Laminator Machine Fully Automatic Laminating

becker pump fully automatic laminating machine

Chain Knife fully automatic laminating machine

Becker Pump Chain Knife Film Laminator

Place of Origin:

CHINA

Brand Name:

MTM/DINGXING

Certification:

ISO/CE

Model Number:

MTM-145E3

Request A Quote

Becker Pump Chain Knife Film Laminator Machine Fully Automatic Laminating

Product Details

Max. Laminating Width (mm):

1080

Max Sheet W×L (mm):

1080X1450

Min Sheet W×L (mm):

350×350

Paper Thickness (gsm):

100-500

Highlight:

becker pump fully automatic laminating machine

Chain Knife fully automatic laminating machine

Becker Pump Chain Knife Film Laminator

Payment & Shipping Terms

Minimum Order Quantity

Packaging Details

Meteorological anti-rust film and steel bottom bracket

Delivery Time

30 DAYS

Payment Terms

L/C, D/A, D/P, T/T

Supply Ability

10 SET/MONTH

Automatic Feeder Thermal Chain Knife Film Laminator Machine 68kW MTM-108E3

Get Best Price

PLC Chain Knife Film Laminator Machine 1080×950mm Thermal Laminating Machine

Get Best Price

Chain Cutter Thermal Film Laminating Machine Fully Automatic 68kW

Get Best Price

ISO Chain Knife Film Laminator Machine Hot Knife Thermal Film Laminator

Get Best Price

+86 18678943457

tony@dingxingmachinery.com

86-515-85571076

Contact Now

Product Description

MTM-145E3 Film Laminator Equip with Chain Knife

Description

Quantity

Automatic Chain Knife Film Laminator 1 SET Model: MTM-108E3

Becker Pump Chain Knife Film Laminator Machine Fully Automatic Laminating 0

Automatic Hot Knife Film Laminator

Hot knife cutting blade is suitable for all films, especially PET film,metalized films(metpet) etc..

General features:

●High efficient: Power consumption of hot knife is as low as 0.4kW.

●No tail film: knife blade temperatures rose to 400 °C within 3 seconds to ensure net and quick cutting.

●High Speed Cut: 80 meters per minute.

●High cut accuracy: Double laser self-aligning device ensures perfect cutting effect.

●High precision ceramic anilox coating roller as standard to ensure super even gluing, no glue stripes, longer roller life, anti-corrosion, glue saving(5g/sqm).

●Non-stop paper feeder system enables continuous feeding without machine stop to minimize waste film.

●Electric thermal powder-removal system ensures clean paper surface to enhance lamination quality.

●Electric glue drying system combined with heat recirculation system to guarantee quick heating to dry the glue and power saving.(30kW consumption in production)

Specification Sheet

MODEL	MTM-108E	MTM-145E
Max. laminating width (mm)	1080	1080
Max sheet W×L (mm)	1080×950	1080X1450
Min sheet W×L (mm)	350×350	350×350
Paper thickness (gsm)	100-500	100-500
Film thickness (µm)	6--25	6--25
Machine speed (m/min)	10-70	10-70
Machine Dimension LWH (mm)	1076527542926	1299427542926
Machine weight (kgs)	8600	10200
Total power (kw)	68kW 30kW(Production)	68kW 30kW(Production)

Becker Pump Chain Knife Film Laminator Machine Fully Automatic Laminating 1
