PLC Control Cardboard High Speed Flute Laminator 150m/Min

PLC Control Cardboard High Speed Flute Laminator 150m/Min
PLC Control Cardboard High Speed Flute Laminator 150m/Min PLC Control Cardboard High Speed Flute Laminator 150m/Min PLC Control Cardboard High Speed Flute Laminator 150m/Min PLC Control Cardboard High Speed Flute Laminator 150m/Min

Large Image :  PLC Control Cardboard High Speed Flute Laminator 150m/Min

Product Details:
Place of Origin: China
Brand Name: DINGXING/DINGYI
Certification: ISO/CE
Model Number: DX-1650
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 20000-50000/SET
Packaging Details: Meteorological anti-rust film and steel bottom bracket
Delivery Time: 30 DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 15 SET/MONTH

PLC Control Cardboard High Speed Flute Laminator 150m/Min

Description
Max. Speed: 150m/min Top Sheet GSM: 120-600
Bottom Sheet Thickness: 0.5mm-10mm Lamination Accuracy: ±1mm
High Light:

PLC Control cardboard laminator

,

High Speed Flute Laminator 150m/Min

,

150m/Min High Speed cardboard laminator

DX-1650 Sheet to Cardboard Flute Laminator



  DX-1450 DX-1650 DX-1650XL
Max. Size: 1450mm*1450mm 1650mm*1450mm 1650mm*1650mm
Min. Size: 400mm*450mm 400mm*450mm 400mm*450mm
Top Sheet GSM: 120gsm—600g/㎡ 120gsm—600g/㎡ 120gsm—600g/㎡
Bottom Sheet Thickness: 0.5-10mm 0.5-10mm 0.5-10mm
Max. Speed: 30~150m/min 30~150m/min 30~150m/min
Lamination Accuracy: ±1.5mm ±1.5mm ±1.5mm
Total Weight: 7000kgs 7500kgs 7500kgs
Machine Size: 14056mm*2314mm*2560mm 14056mm*2514mm*2560mm 16525mm*2514mm*2560mm
Machine Power: AC380/50HZ/26KW AC380/50HZ/28KW AC380/50HZ/28KW
Suitable Paper Single face(flute A-G), Multi-ply(3-7) corrugated cardboard, grey paperboard, paper board over 300 GSM.





PLC Control Cardboard High Speed Flute Laminator 150m/Min 0





• Servo shaftless back feeder, make the top sheet feeding paper overlap, fast and efficiency.



PLC Control Cardboard High Speed Flute Laminator 150m/Min 1



• Dual servo bottom sheet feeder ensures smooth feeding of warping and multi-ply paperboards.



PLC Control Cardboard High Speed Flute Laminator 150m/Min 2



• Computerized high-speed lamination at max.speed of 12,000 sheets per hour(Paper length:600mm)

• Feeder Base: Low E-type piling table ensures direct paper feeding by pallet cart. Railway truck pre-loader is optional.

PLC Control Cardboard High Speed Flute Laminator 150m/Min 3

• Gluing System:High-precision gluing rollers, glue side stopper, auto glue level controller, no overflow at high speed and glue recirculation system.



PLC Control Cardboard High Speed Flute Laminator 150m/Min 4



• Compensation Aligning System: multiple sensors detect relative position of bottom paper,while servo motors ensure dependent upper paper delivery compensation to guarantee precise aligning of two sheets.



PLC Control Cardboard High Speed Flute Laminator 150m/Min 5PLC Control Cardboard High Speed Flute Laminator 150m/Min 6



• Electrical Control System: Human Machine Interface with PLC control, warning light indicator, automatic detection of production condition,irregularities and job record. CE certified.

PLC Control Cardboard High Speed Flute Laminator 150m/Min 7
