Grey Paperboards 5Ply Flute Laminating Machine Middle Speed DW-1650

Grey Paperboards 5Ply Flute Laminating Machine Middle Speed DW-1650

Grey Paperboards flute laminating machine

5Ply Grey cardboard laminating machine

Flute Laminating Machine Middle Speed

Place of Origin:

China

Brand Name:

DINGXING/DINGYI

Certification:

ISO/CE

Model Number:

DW-1650

Contact Us
Request A Quote
Grey Paperboards 5Ply Flute Laminating Machine Middle Speed DW-1650 Grey Paperboards 5Ply Flute Laminating Machine Middle Speed DW-1650 Grey Paperboards 5Ply Flute Laminating Machine Middle Speed DW-1650 Grey Paperboards 5Ply Flute Laminating Machine Middle Speed DW-1650
Product Details
Max. Speed:
5000 Piece/Hour
Top Sheet GSM:
120-600
Bottom Sheet GSM:
300-800
Lamination Accuracy:
±1.5mm
Highlight:

Grey Paperboards flute laminating machine

,

5Ply Grey cardboard laminating machine

,

Flute Laminating Machine Middle Speed

Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD 40000-60000/SET
Packaging Details
Meteorological anti-rust film and steel bottom bracket
Delivery Time
60 DAYS
Payment Terms
L/C, D/A, D/P, T/T
Supply Ability
5 SET/MONTH
RELATED PRODUCTS
Good price PLC Control Cardboard High Speed Flute Laminator 150m/Min online

PLC Control Cardboard High Speed Flute Laminator 150m/Min

Get Best Price
Good price 300-800gsm Bottom Sheet Paperboard Flute Laminator Machine 5000 Piece /H online

300-800gsm Bottom Sheet Paperboard Flute Laminator Machine 5000 Piece /H

Get Best Price
Good price 120-600gsm Top Sheet Auto Flute Laminator 3Ply Corrugated Laminating Machine online

120-600gsm Top Sheet Auto Flute Laminator 3Ply Corrugated Laminating Machine

Get Best Price
Good price Middle Speed 1300*1100mm Auto Flute Laminator Machine DF-1300 online

Middle Speed 1300*1100mm Auto Flute Laminator Machine DF-1300

Get Best Price
Contact Us
+86 18678943457
tony@dingxingmachinery.com
86-515-85571076
Contact Now
Product Description

DW-1650 5Ply Middle Speed Flute Laminator

Main Features



  • Automatic 5Ply Flute Laminator is fortified model adopting two bottom feeders and one top feeder, especially suitable for laminating two single flutes and one top cardboard into 5 ply or two single flutes into corrugated boards, also acting as a regular flute laminator to transfer thicker and large-sized boards smoothly and freely, operator friendly.

  • Automatic 5Ply Flute Laminator is applied in broad scope of papers, substrate papers from cardboards, grey paperboards, single layer/ three/five layers corrugated boards which can be laminated easily and accurately, and total boards from 2 bottom feeders are maximum 8 layers

Model

Modelo

DW-1650

Max. SheetSize(WxL)

Tamaño máximo (WxL)

1650x1400mm(65x55’)



Min. Sheet Size(WxL)

Tamaño mínimo de tabla

450x450mm(18x18’)

Thickness of litho

Espesor de Litho

150~800gsm

Thickness of middle

Espesor de medio

300-800gsm(single flute)

Thickness of substrate

Espesor del sustrato

300~800gsm (Up to 10mm Thick)

A~N Single Layer/ 3/5Layers Corrugated Boards, Grey Paperboards and Cardboards

Accuracy

Precisión de laminado

±2mm(Subject to Paper Quality and Specifications)

Speed

velocidad

0 -5000sheets/hour(Subject to Paper Quality and Specifications)

Power

Longitud total

 AC~380V(30HP)

Total weight

Peso todo

 9800kg



Grey Paperboards 5Ply Flute Laminating Machine Middle Speed DW-1650 0Grey Paperboards 5Ply Flute Laminating Machine Middle Speed DW-1650 1
