1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL

1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL

1650mm*1650mm Flute Laminator Machine

28KW automatic flute laminator

Automatic Flute Laminator Machine 28KW

Place of Origin:

China

Brand Name:

DINGXING/DINGYI

Certification:

ISO/CE

Model Number:

DX-1650XL

Contact Us
Request A Quote
1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL
Product Details
Max. Speed:
150m/min
Top Sheet GSM:
120-600
Bottom Sheet Thickness:
0.5mm-10mm
Lamination Accuracy:
±1mm
Highlight:

1650mm*1650mm Flute Laminator Machine

,

28KW automatic flute laminator

,

Automatic Flute Laminator Machine 28KW

Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD 20000-50000/SET
Packaging Details
Meteorological anti-rust film and steel bottom bracket
Delivery Time
30 DAYS
Payment Terms
L/C, D/A, D/P, T/T
Supply Ability
15 SET/MONTH
RELATED PRODUCTS
Good price PLC Control Cardboard High Speed Flute Laminator 150m/Min online

PLC Control Cardboard High Speed Flute Laminator 150m/Min

Get Best Price
Good price 300-800gsm Bottom Sheet Paperboard Flute Laminator Machine 5000 Piece /H online

300-800gsm Bottom Sheet Paperboard Flute Laminator Machine 5000 Piece /H

Get Best Price
Good price 120-600gsm Top Sheet Auto Flute Laminator 3Ply Corrugated Laminating Machine online

120-600gsm Top Sheet Auto Flute Laminator 3Ply Corrugated Laminating Machine

Get Best Price
Good price Middle Speed 1300*1100mm Auto Flute Laminator Machine DF-1300 online

Middle Speed 1300*1100mm Auto Flute Laminator Machine DF-1300

Get Best Price
Contact Us
+86 18678943457
tony@dingxingmachinery.com
86-515-85571076
Contact Now
Product Description

DX-1650XL Sheet to Cardboard Flute Laminator



  DX-1450 DX-1650 DX-1650XL
Max. Size: 1450mm*1450mm 1650mm*1450mm 1650mm*1650mm
Min. Size: 400mm*450mm 400mm*450mm 400mm*450mm
Top Sheet GSM: 120gsm—600g/㎡ 120gsm—600g/㎡ 120gsm—600g/㎡
Bottom Sheet Thickness: 0.5-10mm 0.5-10mm 0.5-10mm
Max. Speed: 30~150m/min 30~150m/min 30~150m/min
Lamination Accuracy: ±1.5mm ±1.5mm ±1.5mm
Total Weight: 7000kgs 7500kgs 7500kgs
Machine Size: 14056mm*2314mm*2560mm 14056mm*2514mm*2560mm 16525mm*2514mm*2560mm
Machine Power: AC380/50HZ/26KW AC380/50HZ/28KW AC380/50HZ/28KW
Suitable Paper Single face(flute A-G), Multi-ply(3-7) corrugated cardboard, grey paperboard, paper board over 300 GSM.







1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 0





• Servo shaftless back feeder, make the top sheet feeding paper overlap, fast and efficiency.



1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 1



• Dual servo bottom sheet feeder ensures smooth feeding of warping and multi-ply paperboards.



1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 2



• Computerized high-speed lamination at max.speed of 12,000 sheets per hour(Paper length:600mm)

• Feeder Base: Low E-type piling table ensures direct paper feeding by pallet cart. Railway truck pre-loader is optional.

1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 3

• Gluing System:High-precision gluing rollers, glue side stopper, auto glue level controller, no overflow at high speed and glue recirculation system.



1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 4



• Compensation Aligning System: multiple sensors detect relative position of bottom paper,while servo motors ensure dependent upper paper delivery compensation to guarantee precise aligning of two sheets.



1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 51650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 6



• Electrical Control System: Human Machine Interface with PLC control, warning light indicator, automatic detection of production condition,irregularities and job record. CE certified.

1650mm*1650mm Automatic Flute Laminator Machine 28KW DX-1650XL 7
