Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning

Description
Max. Working Size: 2100mm*1650mm Min. Working Size: 600mm*600mm
Max. Speed: 10000 Piece/Hour Automation: Aotumatic Stacker Out And Pallet Change
High Light:

Fully Intermittent Turning Automatic Sheet Stacker

,

Flip Flop automatic stacker machine

,

Fully Intermittent Turning Flip Flop Stacker

FZ-2100 Auto Flip Flop Stacker

Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 0



Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 1



Automatic Flip Flop Stacker

In order to achieve best efficiency for High Speed Laminator, this flip flop stacker is to track the speed of the laminator and collect laminated sheets in piles neatly and automatically, and be integrated into one production line with flute laminator to increase efficiency.



Description:



1, Integrated with flute laminator to ensure automatic collection, stacking of laminated sheets.

2, Fully intermittent turning, flip-flop stacking sheets into an organised and smooth piling.

3, Stacked by one pile of up and one pile of down or two piles up and two piles down subject to paper thickness and job request.

4. Automatic paper pile height setting.

5.Touch screen operation, user-friendly and easy to run.

6 Time-saving, labor-saving and production efficient.

7. Max speed is 10000 sheets per hour.

Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 2



Specifications:

Model FZ-2100
Max. Sheet Size 2100(W)*1650(L)(mm)
Min. Sheet Size 600(W)*600(L)(mm)
Max. Speed 6000-1000Sheets/hour (Subject to paper quality and size)
Total Power Required 9 KW

Specifications are subject to change without notice



Laminated Sheets Separation System

Main purpose is to separate the heavily overlapped sheets from pressing conveyor of laminator and deliver laminated sheets to paper collection system



Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 3





Pre-stack System

Pre-stack system is to collect with laminated sheets separation system, and stack one pile of sheets neatly and deliver to flip flop system. Stack height is adjustable by entering number of sheets into HMI and paper push is driven by motor



Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 4



Touch Screen (HMI)

To enter paper size, paper quantity and start the machine running.

Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 5





Paper Flip Flop System



Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 6

Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 7



Paper Loosening System



Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 8

Paper Lifting System



Paper lifting system is driven by Innovance servo motor



Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 9





Paper Collecting System

Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 10

Paper Delivery System

Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 11



Control Cabinet

Flip Flop Automatic Sheet Stacker Machine Fully Intermittent Turning 12
