Home > products > Litho Lamination Machine >
Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic

Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic

Corrugated Sheet To Sheet Lamination Machine

Fully Automatic corrugated box lamination machine

28KW corrugated box lamination machine

Place of Origin:

CHINA

Brand Name:

DINGXING/DINGYI

Certification:

ISO/CE

Model Number:

DX-1650XL

Contact Us
Request A Quote
Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic
Product Details
Color:
Customizable
Function:
Two Sheet Lamination
Part Brand:
International Professional Leading Brand
Maximum Speed:
150m/min
Highlight:

Corrugated Sheet To Sheet Lamination Machine

,

Fully Automatic corrugated box lamination machine

,

28KW corrugated box lamination machine

Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD 25000-40000/SET
Packaging Details
Meteorological anti-rust film and steel bottom bracket
Delivery Time
30 DAYS
Payment Terms
L/C, D/A, D/P, T/T
Supply Ability
20 SET/MONTH
RELATED PRODUCTS
Good price 120m/min Litho Lamination Machine CE Corrugated To Printed Paper online

120m/min Litho Lamination Machine CE Corrugated To Printed Paper

Get Best Price
Good price Auto 120gsm-600gsm Top Sheet Litho Lamination Machine 150m/Min online

Auto 120gsm-600gsm Top Sheet Litho Lamination Machine 150m/Min

Get Best Price
Good price Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic online

Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic

Get Best Price
Good price Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine online

Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine

Get Best Price
Contact Us
+86 18678943457
tony@dingxingmachinery.com
86-515-85571076
Contact Now
Product Description

DX-1650XL HIGH SPEED FLUTE LAMINATOR



  DX-1450 DX-1650 DX-1650XL
Max. Size: 1450mm*1450mm 1650mm*1450mm 1650mm*1650mm
Min. Size: 400mm*450mm 400mm*450mm 400mm*450mm
Top Sheet GSM: 120gsm—600g/㎡ 120gsm—600g/㎡ 120gsm—600g/㎡
Bottom Sheet Thickness: 0.5-10mm 0.5-10mm 0.5-10mm
Max. Speed: 30~150m/min 30~150m/min 30~150m/min
Lamination Accuracy: ±1.5mm ±1.5mm ±1.5mm
Total Weight: 7000kgs 7500kgs 7500kgs
Machine Size: 14056mm*2314mm*2560mm 14056mm*2514mm*2560mm 16525mm*2514mm*2560mm
Machine Power: AC380/50HZ/26KW AC380/50HZ/28KW AC380/50HZ/28KW
Suitable Paper Single face(flute A-G), Multi-ply(3-7) corrugated cardboard, grey paperboard, paper board over 300 GSM.

Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic 0Corrugated Box Sheet To Sheet Lamination Machine 28KW Fully Automatic 1
