Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine

Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine
Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine

Large Image :  Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine

Product Details:
Place of Origin: CHINA
Brand Name: DINGXING/DINGYI
Certification: ISO/CE
Model Number: DX-1650XL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 30000-80000/SET
Packaging Details: Meteorological anti-rust film and steel bottom bracket
Delivery Time: 30 DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10 SET/MONTH

Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine

Description
Color: Customizable Function: Two Sheet Lamination
Part Brand: International Professional Leading Brand Main Market: Europe And North America
High Light:

Front Edge High Speed Flute Laminator

,

5ply Corrugated Laminating Machine

,

Front Edge Corrugated Laminating Machine

DX-1650XL Front Edge HIGH SPEED FLUTE LAMINATOR



  DX-1450 DX-1650 DX-1650XL
Max. Size: 1450mm*1450mm 1650mm*1450mm 1650mm*1650mm
Min. Size: 400mm*450mm 400mm*450mm 400mm*450mm
Top Sheet GSM: 120gsm—600g/㎡ 120gsm—600g/㎡ 120gsm—600g/㎡
Bottom Sheet Thickness: 0.5-10mm 0.5-10mm 0.5-10mm
Max. Speed: 30~150m/min 30~150m/min 30~150m/min
Lamination Accuracy: ±1.5mm ±1.5mm ±1.5mm
Total Weight: 7000kgs 7500kgs 7500kgs
Machine Size: 14056mm*2314mm*2560mm 14056mm*2514mm*2560mm 16525mm*2514mm*2560mm
Machine Power: AC380/50HZ/26KW AC380/50HZ/28KW AC380/50HZ/28KW
Suitable Paper Single face(flute A-G), Multi-ply(3-7) corrugated cardboard, grey paperboard, paper board over 300 GSM.





Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine 0Front Edge High Speed Flute Laminator 3ply 5ply Corrugated Laminating Machine 1
