100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW

Certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
I'm Online Chat Now

100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW

100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW
100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW 100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW 100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW 100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW

Large Image :  100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW

Product Details:
Place of Origin: CHINA
Brand Name: DINGXING/DINGYI
Certification: ISO/CE
Model Number: DF-1650EL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 30000-50000/SET
Packaging Details: Meteorological anti-rust film and steel bottom bracket
Delivery Time: 30 DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 25 SET/MONTH

100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW

Description
Maximum Speed: 120m/min Maximum Size: 1650*1650
Quantity Of Servo System: 2 Sets Remote System: Optional
High Light:

100 sheets /min corrugated laminating machine

,

Corrugated Paperboard Laminating Machine 19KW

,

100 sheets /min Paperboard Laminating Machine

DF-1650EL Middle Speed Flute Laminator



DF-1650EL
Max. Size: 1650mm*1650mm
Min. Size: 450mm*450mm
Top Sheet GSM: 120g/㎡—800g/㎡
Bottom Sheet Thickness: 300g/㎡—800g/㎡
Max. Speed: 0-100sheets/min
Lamination Accuracy: ±1.5mm
Total weight: 7500kgs
Machine Size: 15005mm*2670mm*2500mm
Machine Power: AC-380V/50HZ/19KW





100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW 0100 Sheets /Min Corrugated Paperboard Laminating Machine 19KW 1
