120m/min Litho Lamination Machine CE Corrugated To Printed Paper

Certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
China Dongtai Dingxing Machinery Technology Co., Ltd certification
I'm Online Chat Now

120m/min Litho Lamination Machine CE Corrugated To Printed Paper

120m/min Litho Lamination Machine CE Corrugated To Printed Paper
120m/min Litho Lamination Machine CE Corrugated To Printed Paper 120m/min Litho Lamination Machine CE Corrugated To Printed Paper 120m/min Litho Lamination Machine CE Corrugated To Printed Paper 120m/min Litho Lamination Machine CE Corrugated To Printed Paper

Large Image :  120m/min Litho Lamination Machine CE Corrugated To Printed Paper

Product Details:
Place of Origin: CHINA
Brand Name: DINGXING/DINGYI
Certification: ISO/CE
Model Number: DX-1650
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 50000-70000/SET
Packaging Details: Meteorological anti-rust film and steel bottom bracket
Delivery Time: 30 DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 30 SET/MONTH

120m/min Litho Lamination Machine CE Corrugated To Printed Paper

Description
Maximum Speed: 120m/min Maximum Size: 1650*1650
Quantity Of Servo System: 2 Sets Remote System: Optional
High Light:

120m/Min Litho Lamination Machine

,

Litho Lamination Machine CE

,

120m/Min corrugated laminating machine

  DX-1450 DX-1650 DX-1650XL
Max. Size: 1450mm*1450mm 1650mm*1450mm 1650mm*1650mm
Min. Size: 400mm*450mm 400mm*450mm 400mm*450mm
Top Sheet GSM: 120gsm—600g/㎡ 120gsm—600g/㎡ 120gsm—600g/㎡
Bottom Sheet Thickness: 0.5-10mm 0.5-10mm 0.5-10mm
Max. Speed: 30~150m/min 30~150m/min 30~150m/min
Lamination Accuracy: ±1.5mm ±1.5mm ±1.5mm
Total Weight: 7000kgs 7500kgs 7500kgs
Machine Size: 14056mm*2314mm*2560mm 14056mm*2514mm*2560mm 16525mm*2514mm*2560mm
Machine Power: AC380/50HZ/26KW AC380/50HZ/28KW AC380/50HZ/28KW
Suitable Paper

Single face(flute A-G), Multi-ply(3-7) corrugated cardboard, grey paperboard, paper

board over 300 GSM.

120m/min Litho Lamination Machine CE Corrugated To Printed Paper 0
